SPECIFICATIONS
Rims
- Material: Maxtal
- Height: 22 mm
- Disc brake specific profile
- Tire: UST Tubeless and tubetype
- Internal width: 22 mm
- ETRTO size: 622x22TSS ROAD
- Hookless profile
- Fore
- UST
- SUP
Spokes
- Material: steel
- Shape: straight pull, flat, double butted
- Nipples: Fore integrated aluminum
- Count: 24 front and rear
- Lacing: front and rear crossed 2, contactless
Hubs
- Front and rear bodies: aluminum
- Axle material: aluminum
- Front: Quick release, 12×100 and 15×100 through axle compatible
- Rear: Quick Release, 12×142 and 12×135 compatible
- Infinity Hub
- Instant Drive 360
- QRM Auto
Versions
- Disc standard: Center Lock (R) only
- Freewheel: Shimano/Sram or XD-Road
Compatibility
- Freewheel: Shimano/Sram, convertible to Campagnolo and XD-R with optional driver bodies
- Front axle: 12mm thru axle, easily convertible to quick release with included adapters. Convertible to 15mm with complete axle replacement
- Rear axle: 12mm thru axle, convertible to Quick Release with optional adapters
Compatible Adapters and freewheel bodies
- 12 to 9mm front adapter for quick release (LV2680300)
- 15mm axle (LV2373500)
- 12mm front hub cap ([LV2680500] – Delivered with the wheel)
- 15mm axle (LVXXXXXX)
- 12 to 9mm rear adapter for quick release ([LV2510800]
- ID360 Shimano / Sram Light freewheel body (LV3850100)
- ID360 Campagnolo freewheel body (LV3440100)
- ID360 XD-R freewheel body (LV2580100)
- ID360 Shimano / Sram freewheel body ([LV3430100] – Delivered on the wheel)
- ID360 N3W freewheel body (V4270101)
Intended use
- ASTM CATEGORY 2 : road and offroad with jumps less than 15cm
- For a longer longevity of the wheel, Mavic recommends that the total weight supported by the wheels doesnn’t exceed 120kg, bike included
- Recommended tyre sizes: 28 to 64 mm (1.1″ to 2.5″)
- Max. Pressure: see indication on wheel and tyre. If they differ, use the lowest of the 2
Delivered with
- UST valve and accessories
- User guide
