Giant Talon 1 29″

Model Name

Talon 1

Colors

Black, Hematite

Sizes

27.5: XS,S,M,L

29: S,M,L,XL,XXL

Frame

ALUXX-Grade Aluminum, disc

Fork

SXC32-2 RL, air spring, QR, alloy steerer XS: 80mm travel (27.5) S: 80mm travel (27.5) / 100mm travel (29) M: 100mm travel (27.5) / 100mm travel (29) L: 100mm travel (27.5) / 100mm travel (29) XL: 100mm travel (29) XXL: 100mm travel (29)

Shock

N/A

Handlebar

Giant Connect Trail, 31.8mm XS: 730mm (27.5) S: 780mm (27.5) / 780mm (29) M: 780mm (27.5) / 780mm travel (29) L: 780mm (27.5) / 780mm (29) XL: 780mm (29) XXL: 780mm (29)

Grips

Giant Sole-O

Stem

Giant Sport, 7-degree XS: 40mm (27.5) S: 50mm (27.5) / 50mm (29) M: 60mm (27.5) / 60mm travel (29) L: 70mm (27.5) / 70mm (29) XL: 80mm (29) XXL: 90mm (29)

Seatpost

Giant Sport, 30.9 XS: 300mm (27.5) S: 300mm (27.5) / 375mm (29) M: 375mm (27.5) / 375mm travel (29) L: 375mm (27.5) / 375mm (29) XL: 375mm (29) XXL: 375mm (29)

Saddle

Giant custom

Pedals

MTB caged

Shifters

Shimano Deore M4100, 1×10

Front Derailleur

N/A

Rear Derailleur

Shimano Deore M5120

Brakes

Tektro HDC M275, hydraulic, Tektro rotors [F]180mm, [R]160mm

Brake Levers

Tektro HDC M275

Cassette

Shimano Deore M4100, 11×42

Chain

KMC X10

Crankset

ProWheel Charm, 30t (27.5) or 32t (29) XS: 165mm (27.5) S: 170mm (27.5) / 170mm (29) M: 170mm (27.5) / 175mm travel (29) L: 175mm (27.5) / 175mm (29) XL: 175mm (29) XXL: 175mm (29)

Bottom Bracket

cartridge

Rims

Giant GX03V 29 or 27.5, alloy, double wall, 21mm inner width

Hubs

alloy, sealed bearing

Spokes

stainless, 14g

Tires

Kenda Booster 27.5 or 29×2.4″, wire bead

Extras

2.4″ max tire size
